Industrial Electromagnetic Heater 15-160KW
Model: XF-EM Series
Power: 15-160KW
Voltage: 220V/380V
Application: Injection molding machines, extruders, food processing, chemical reactors, thermal oil furnaces, furnace heating, pipeline heating, plastic machinery
Industrial electromagnetic heater uses electromagnetic induction principle to convert electrical energy to thermal energy with thermal efficiency up to 98%. Suitable for injection molding barrel heating, extruder heating, food drying, chemical reactor heating, thermal oil furnace, furnace heating and industrial applications.
Energy saving 30-60% compared to traditional resistance heating, rapid heating, precise temperature control ±1°C, water-electricity separation for safety. German Infineon IGBT module, WiFi/485 remote control support, PID intelligent temperature control algorithm.
Product Features:
- Temperature range 50-1200°C, covering all industrial heating scenarios
- Thermal efficiency ≥98%, energy saving 30-60%
- Precise temperature control ±1°C, PID intelligent algorithm
- Water-electricity separation, no open flame, zero emissions
- German Infineon IGBT, stable and durable
- WiFi/485 remote control support
- Wall-mounted/floor-standing installation optional
Features
- Energy Efficient: Thermal efficiency up to 98%, saving 30-60% vs resistance heating
- Precise Control: ±1°C precision, PID intelligent temperature control algorithm
- Safe & Reliable: Water-electricity separation, no open flame, zero emissions
- Imported Core: German Infineon IGBT module
- Remote Control: WiFi/485 remote control, custom APP available
- Multiple Coils: Flat coil, arc coil, hemispherical coil optional
- Flexible Installation: Wall-mounted/floor-standing optional
- Wide Application: All magnetic materials above 50mm can be heated
- Multiple Protections: Over-current/over-voltage/over-temperature/phase-loss protection
- Accessories Included: High-temp enameled wire, quick connectors, high-temp cotton, golden finger, fiberglass tape, magnetic probe
| Power Range | 15-160KW (customizable for higher power) |
|---|
| Input Voltage | 220V/380V (Any Phase Sequence) |
|---|
| Thermal Efficiency | ~98% |
|---|
| Temperature Precision | ±1°C |
|---|
| Temperature Range | 50-1200°C |
|---|
| Operating Frequency | 8-20KHz |
|---|
| Cooling Method | Air cooling/Water cooling |
|---|
| IGBT Module | German Infineon |
|---|
| Communication | RS-485 / WiFi (custom APP available) |
|---|
| Installation | Wall-mounted/Floor-standing optional |
|---|
| Coil Types | Flat/Arc/Hemispherical coils |
|---|
| Applicable Materials | Magnetic materials above 50mm (cast iron/carbon steel/stainless steel/graphite, etc.) |
|---|
| Safety Protection | Over-current/Over-voltage/Over-temp/Phase-loss |
|---|
| Control Method | PID intelligent temperature control/Custom APP remote control supported |
|---|
